| Input and Output |
| Wireless Protection Zone |
Hub: 150-channel wireless peripherals (6 sirens, 64 wireless keyfobs) |
| Port |
| Buzzer |
Hub: Built-in |
| Button |
Hub: 1 × reset, 1 × power, 1 × AP
Keyfob: 4 (Home, Away, Disarm, and SOS)
Door Detector: 1 × power button
PIR Detector: 1 × power button |
| Indicator Light |
Hub: 1 for multiple statuses (alarm, arming, disarming, networking, and malfunction)
Keyfob: 1 × two-color status indicator (green: normal, red: abnormal)
Door Detector: 1 × green alarm indicator
PIR Detector: 1 × green alarm indicator |
| Storage battery |
Hub: Built-in lithium battery |
| Network Port |
Hub: 1 × RJ-45 10 M/100 M Ethernet port |
| Function |
| Network Protocol |
Hub: TCP/IP, including PPTP, L2TP, DHCP, UPNP, and NTP |
| Offline Cache |
Hub: Max. 50 entries (ANR) |
| Power Failure Protection for Configured Parameters |
Hub: Yes |
| Remote Update |
All: Cloud update |
| Video Linkage |
Hub: Yes |
| Low Battery Alarm |
All: Yes |
| Tamper Alarm |
Hub: Yes
Door Detector: Yes
PIR Detector: Yes |
| User Management |
Hub: Share function for App users |
| Search |
Hub: Searching push messages, device status, and program version. Detecting signal strength.
Keyfob: Signal strength detection
Door Detector: Signal strength detection
PIR Detector: Signal strength detection |
| Arm and Disarm |
Hub: App; keyfob; schedule |
| Wireless |
| Carrier Frequency |
All: 868.0 MHz–868.6 MHz |
| Communication Distance |
Hub: Up to 2,000 m (6,561.68 ft) in an open space
Keyfob: Up to 900 m (2,952.76 ft) in an open space
Door Detector: Up to 1,200 m (3,937.01 ft) in an open space
PIR Detector: Up to 1,600 m (5,249.34 ft) in an open space |
| Communication Mechanism |
All: Two-way |
| Encryption Mode |
All: AES128 |
| Frequency Hopping |
All: Yes |
| Wi-Fi |
Hub: 2.4G |
| Peripherals |
| External Zone |
Door Detector: 1-channel dry contact input |
| Temperature |
| Measuring Range (Temperature) |
"Door Detector: –15 °C to +65 °C (+18.8 °F to +149 °F) (indoor)
PIR Detector: –15 °C to +65 °C (+18.8 °F to +149 °F) (indoor)" |
| Measuring Precision (Temperature) |
Door Detector: ± 1 °C (± 33.8 °F)
PIR Detector: ± 1 °C (± 33.8 °F) |
| Resolution (Temperature) |
Door Detector: 1 °C (33.8 °F)
PIR Detector: 1 °C (33.8 °F) |
| Specification |
| Sensor |
Door Detector: Reed switch
PIR Detector: Dual elements low-noise PIR sensor |
| Test Mode |
Door Detector: Yes
PIR Detector: Yes |
| Scenario |
Door Detector: Non-metal doors |
| Movement Distance |
Door Detector: < 40 mm (1.57") |
| Detection Mode |
PIR Detector: PIR |
| Detection Range |
PIR Detector: 12 m (39.37 ft) (90°) with installtion height of 2.2 m (7.21 ft) |
| Detection Speed |
PIR Detector: 0.3 m/s–3 m/s (0.98 ft/s–9.84 ft/s) |
| Pet Immunity Level |
PIR Detector: ≤ 18 kg (39.68 lb) |
| White Light Resistance Level |
PIR Detector: 6500 lx |
| Two-way Digital Temperature Compensation |
PIR Detector: Yes, no attenuation of detection distance in high temperature |
| Sensitivity |
PIR Detector: 3 levels adjustable |
| General |
| Power Supply |
Hub: 12 V DC, 1.5 A (Europe, UK and USA power adapters are optional)
Keyfob: CR2032 battery
Door Detector: CR123A battery
PIR Detector: CR123A battery |
| Battery Life |
Hub: Storage battery standby for 12 Hours
Keyfob: 5 years
Door Detector: 5 years
PIR Detector: 4 years |
| Power Consumption |
Keyfob: Max. 100 mW
Door Detector: Max. 125 mW
PIR Detector: Max. 120 mW |
| Operating environment |
Hub: –10 °C to +50 °C (+14 °F to +122 °F) (indoor)
Keyfob: –10 °C to +55 °C (+14 °F to +131 °F) (indoor)
Door Detector: –10 °C to +55 °C (+14 °F to +131 °F) (indoor)
PIR Detector: –10 °C to +55 °C (+14 °F to +131 °F) (indoor) |
| Operating Humidity |
All: 10%–90% (RH) |
| Product Dimensions |
Hub: 163.0 mm × 163.0 mm × 32.0 mm (6.42"" × 6.42"" × 1.26"") (L × W × H)
Keyfob: 60.0 mm × 39.5 mm × 15.0 mm (2.36"" × 1.56"" × 0.59"") (L × W × H)
Door Detector: 100.2 mm × 20.8 mm × 20.3 mm (3.94"" × 0.82"" × 0.80"") (L × W × H)
PIR Detector: 104.0 mm × 60.0 mm × 50.0 mm (4.09"" × 2.36"" × 1.97"") (L × W × H) |
| Packaging Dimensions |
Hub: 219.0 mm × 187.0 mm × 91.0 mm (8.62"" × 7.36"" × 3.58"") (L × W × H)
Keyfob: 135.0 mm × 98.5 mm × 27.8 mm (5.31"" × 3.88"" × 1.09"") (L × W × H)
Door Detector: 135.0 mm × 98.5 mm × 27.8 mm (5.31"" × 3.88"" × 1.09"") (L × W × H)
PIR Detector: 135.0 mm × 98.5 mm × 56.8 mm (5.31"" × 3.88"" × 2.24"") (L × W × H) |
| Installation |
Hub: Wall mount; Desktop
Door Detector: Bracket mount
PIR Detector: Wall mount |
| Net Weight |
Hub: 0.38 Kg (0.84 lb)
Keyfob: 20 g (0.04 lb)
Door Detector: 70 g (0.15 lb)
PIR Detector: 100 g (0.22 lb) |
| Gross Weight |
Hub: 0.8 Kg (1.76 lb)
Keyfob: 65 g (0.14 lb)
Door Detector: 115 g (0.25 lb)
PIR Detector: 170 g (0.37 lb) |
| Casing |
All: PC + ABS |
| Certifications |
All: CE |
